KD700 · Machinery Diagnostics - Base Unit

Base unit with vibration analyser

Experiments
  • Introduction to vibration measurement methods on rotating machinery systems
  • Fundamentals of shaft and bearing vibration measurement - variables, sensors, signal types
  • Influence of speed, shaft layout and sensor positioning on the measured vibration signal
  • Field balancing of rigid rotors in one and two planes
  • Misalignment between motor and shaft, and its correction by shaft alignment
  • Mechanical looseness - effect of a loosened mounting on the vibration spectrum
  • Interpretation of frequency spectra of rotating machinery
  • Use of a computerised vibration analyser for time- and frequency-domain analysis
  • Quick vibration and non-contact temperature checks at the machine with the portable meter
KD700
Description
    The KD700 is the modular base bench of the Sangari machinery diagnostic training system. A three-phase asynchronous motor with frequency converter drives a shaft with two flywheels in interchangeable bearing blocks, under an interlocked transparent cover. Unbalance, misalignment and mechanical looseness are set up on the bench, then measured and corrected. The unit is supplied ready to measure, with accelerometers, a computerised vibration analyser and a portable vibration meter, and stands on a support frame with anti-vibration mounts. Its rigid aluminium plate with slots allows quick, precise assembly of further setups - belt drives, gears, couplings and pumps - when combined with the KD710-KD719 expansion experiments.
KD700 base unit - schematic
Drive motor on adjustable carriage
Coupling
Base plate with M8 slots
Shaft with flywheel
Bearing blocks
Transparent protective cover
KD700 base unit - schematic
Drive motor on adjustable carriage
Coupling
Base plate with M8 slots
Shaft with flywheel
Bearing blocks
Transparent protective cover
Overview
    KD700 front view
Specifications
    Base plate 1100 × 800 mm aluminium with M8 slots, 50 mm spacing
    Drive motor three-phase asynchronous, 0.25 kW
    Speed range 100…6000 min⁻¹ via frequency converter
    Shafts 2 × Ø 20 mm; lengths 300 and 500 mm
    Flywheels 2 × Ø 150 mm, 1675 g, with interchangeable balance bolts
    Bearings 2 bearing blocks, deep groove ball bearings 6004, interchangeable
    Coupling flexible claw + Controlflex™, nominal torque 15 Nm
Measurement and Analysis
    Vibration sensors accelerometers for the sensor points on the bearing blocks
    Vibration analyser computerised, operated from a PC
    Software time signal, FFT spectrum and envelope analysis; display, recording and analysis of vibration spectra
    Measured quantities acceleration, velocity and displacement
    Balancing field balancing in one and two planes
    Portable meter portable vibration meter with infrared thermometer for non-contact temperature measurement
    Shaft alignment alignment tools for motor and shaft
Scope of Delivery
  • Base bench with drive motor, coupling, 2 shafts, 2 flywheels and 2 bearing blocks
  • Control unit with frequency converter
  • Transparent protective cover with safety interlock
  • Support frame with anti-vibration mounts
  • Accelerometers and computerised vibration analyser
  • Vibration analysis software
  • Portable vibration meter with infrared thermometer
  • Alignment tools
  • Set of balance bolts
  • Set of instructional materials

All components and accessories listed under Scope of Delivery are supplied, whether or not they are visible in the illustrations.

Specifications (continued)
    Motor alignment adjustable obliquely and transversally via carriage
    Fault simulation unbalance, misalignment and mechanical looseness
    Safety transparent protective cover; motor cuts off automatically when cover is opened
    Control unit digital displays for power output and speed
    Power supply 230 V, 50 Hz, single-phase; the frequency converter feeds the three-phase motor
    Support frame with anti-vibration mounts
    Dimensions base + cover 1100 × 800 × 500 mm; control unit 475 × 420 × 200 mm
    Weight approx. 95 kg
