Virtual laboratories
Open your apparatus
Each apparatus comes with its own laboratory: the Student's Handbook, the experiments, and a live interface that mirrors the real apparatus. Inside, choose where the readings come from - none, a simulation, or the apparatus itself over USB.
Thermodynamics
Heat transfer and conductivity
Experimental apparatus for measuring thermal conductivity through metal specimens.
Open laboratory →
Experimental apparatus for studying heat conduction along the radius of a brass disc - the temperature profile, Fourier's law in cylindrical form and λ of brass.
Open laboratory →
Experimental apparatus for studying convective heat transfer in a tube with forced air.
Open laboratory →
Experimental apparatus for the study of conduction and convection.
Open laboratory →
Base unit with three interchangeable heat exchanger modules - tubular (TH551), plate (TH552) and shell & tube (TH553) - compared in co-current and counter-current operation.
Open laboratory →
Experimental apparatus for studying heat pumps for heating and cooling - vapor-compression cycle.
Open laboratory →
