FM565 · Pipe Networks

Experimental Apparatus for the Study of Pipe Networks

The analysis of a hydraulic system involves determining the flow rate distribution across the pipes of the system and the pressure at each network node, by applying the continuity equation at the nodes and the energy balance between the various nodes of the system.
FM565
Experiments
  • Head losses and hydraulic head for all configurations under study
  • Hydraulic resistance moduli of individual pipe segments
  • Equivalent resistance moduli of series-coupled pipes - definition verification
  • Equivalent resistance moduli of parallel-coupled pipes - definition verification
  • Equivalent resistance moduli of mixed-coupled pipes - definition verification
  • Head loss balance around the loop in a single-loop ring network
    • Schematic diagram of the FM565 apparatus - pipe networks
    Pump
    Reservoir
    Pipe segments
    Valves
    Schematic diagram of the FM565 apparatus - pipe networks
    Schematic diagram of the FM565 apparatus - pipe networks
    Pump
    Reservoir
    Pipe segments
    Valves
    Schematic diagram of the FM565 apparatus - pipe networks
Specifications

    Five categories of hydraulic systems are studied:

    • Individual pipe segments
    • Series, parallel, and mixed coupling
    • Single-loop ring network
    Reservoir capacity 200 l
    Pipe segment length 700 mm
    Nominal cross-sections 25×1.9 mm (1 pc.), 20×1.5 mm (2 pcs.)
    Flow rate measurement electromagnetic flow transducer
    Pump 550 W, max. head 11 m, max. flow rate 12 m³/h
    Pipe coupling series, parallel, and mixed
    Ring network single-loop
    Pressure measurement water U-tube manometers, H = 1 m
